DS201 M B10 AC30
DS201 M B10 AC30Zobrazit více +
Skladem ext.
Cena po registraci:1 626,00 Kč s DPH
DS201 M B10 AC30; kombinace jistič/chránič; dvojpólový (1P+N); jmenovitý proud: 10A; citlivost: 30mA; charakteristika: B; zkratová odolnost: 10kA; Typ: AC – pro střídavý reziduální proud (určeno pro obecné zátěže)
| Number of poles (total): | 2 |
| Number of protected poles: | 1 |
| Rated voltage: | 240 |
| Rated insulation voltage Ui: | 500 |
| Rated impulse withstand voltage Uimp: | - |
| Rated current: | 10 |
| Rated fault current: | 0.03 |
| Leakage current type: | AC |
| Current limiting class: | 3 |
| Rated short-circuit breaking capacity according to EN 61009: | 10 |
| Rated short-circuit breaking capacity according to IEC 60947-2: | 15 |
| Rated short-circuit breaking capacity Icn according to EN 61009-1: | - |
| Disconnection characteristic: | - |
| Voltage type: | AC |
| Frequency: | 50/60 Hz |
| Release characteristic: | B |
| Concurrently switching neutral conductor: | true |
| With interlocking device: | false |
| Over voltage category: | - |
| Pollution degree: | 2 |
| Ambient temperature during operating: | -13 |
| Ambient temperature during operating: | -25 |
| Width in number of modular spacings: | 2 |
| Built-in depth: | 2.71653 |
| Built-in depth: | 69 |
| Flush-mounted installation: | false |
| Anti-nuisance tripping version: | false |
| Degree of protection (IP): | IP20 |
| Connectable conductor cross section solid-core: | - |
| Connectable conductor cross section solid-core: | - |
| Connectable conductor cross section multi-wired: | - |
| Connectable conductor cross section multi-wired: | - |
